Product Quick detail
1. Anti-UV transparent PC cover, won't turn yellow within 2 years.
2. The copper GX16D base, great electrical conductivity.
3. Aluminum material +ANTI UV PC cover, no yellowing or dazzling for two years.
4. IP Rate: IP68 Structural waterproof.
5. 8 hours aging testing, 30 steps quality inspections, assure the great quality pool light.
Specification
| HG-P56-18W-B-RGB(GX16D-L)-T-UL |
| Lamp parameter | Material | Aluminum+Anti UV PC cover |
| Light dimension | Φ177×118mm |
| Input voltage | AC12V |
| Wattage | 17W±10％ |
| Light lumen | 520LM±10％ |
| Beam angle | 120° |
| BASE | GX16D |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC,UL |
| Life-span | 50,000 hours |
| Warranty | 2Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120V/220V coil transformer |
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED PAR56 swimming pool lights (Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 62 | 65 |
Dimension
Application
HG-P56-18W-B-RGB(GX16D-L)-T-UL led pool lighting widely use in concrete pool,vinyl pool, the lamp
size can totally match various Germany and US PAR56 housing/niches.
Some tips for you
Q1: How to choose the right LED energy saving lamps?
Low watage with high Lumen. This will save more electricity bill.
Q2: What is the advantages of LED?
Environmental friendly, Energy saving and Long lifespan.
Q3: The key factor that influence LED lifespan.
Temperature: It requires that junction temperature of LED chip should be ≤120℃,
so the center temperature at the LED bottom of light board should be ≤ 80 ℃.
Q4: Why choose us?
1. Lower wattage with high Lumen and more energy-efficient.
2. All lamps are self-developed patent products.
3. IP68 structure waterproof without glue, and lamps disspate heat through structure.
4. According to the LED characteristic, the center temperature at the LED bottom of light board must
be controlled strictly( ≤ 80 ℃).
5. High quality driver of lamps to ensure the long lifespan.
6. All products have passed CE, ROHS, FCC, IP68, and our Par56 pool light have got UL certification.
7. All products need to pass 30 steps QC inspection, the quality has the guarantee, and the faulty rate
is less than three per thousand .
